Product Details:
|
Private Mold: | Yes | Style: | USB Microphone, Desktop, Shock Mount, Wired Microphone, Handheld Microphone With Speaker |
---|---|---|---|
Communication: | Wired | Use: | COMPUTER MICROPHONE, Conference Microphone, Karaoke Microphone, Church, Stage Performance, INTERVIEW, Speech, Recording, SINGING, Teaching, Portable Audio Player, Communication, Broadcasting, Kids, Gaming |
Material: | Metal, Plastic | Function: | Noise Cancelling, Light-weight, PORTABLE, Condenser Microphone, With Sound Card |
Polar Pattern: | Cardioid, Cardioid,Omni,Figure-8 | Type: | Tube Condenser Microphone |
Signal To Noise Ratio: | 79dBA | Frequency Response Rate: | 20Hz-20KHz |
Maximum SPL: | 123db(1%T.H.D.@1kHz) | Sensitivity: | -28dB,39.8mV/Pa(0dB=1V/Pa@1kHz) |
Product Name: | Professional Condenser Microphone | Brand: | 797Audio |
Model No.: | ATCR01 | Sensitivity(dB)(1000Hz): | -42dB(7.9mV/Pa) |
Recommended Input Impedance: | Less Than 1000 Ohms | Frequency Range(Hz): | 20-20,000 |
Max.SPL(dB)(1000HzTHD<1%): | 149dB SPL | Power Requirements: | 48V DC Phantom |
Matching Connector: | 3-pin XLR |
Technical Data |
|
Product | Tube Condenser Microphone |
Model | ATCR01 |
Brand | 797AUDIO |
Capsule | 1.1inch Large Diaphragm Gold-plated Capsule |
Polar Pattern | Cardioid |
Frequency Range(Hz) | 20-20,000Hz |
Sensitivity(dB) | -28dB,39.8mV/Pa(0dB=1V/Pa@1kHz) |
Output Impedance (ohm)(1000Hz) | ≤200Ω |
Max.SPL(dB) | 123dB(1%T.H.D.@1kHz) |
Equivalent Noise Level(dB) | 15dBA |
S/N(dB FS) | 79dBA |
Power | USB 5V 260mA |
Weight | 850g |
Length | 230mm |
Supply Service | 797Audio Brand,OEM,ODM |
Delivery Terms | By sea, By Express,By Air, By Train |
Applications | Interview, Live Chat, Recording, Broadcasting, Conference, Speech, Gaming,Singing, Entertainment,Etc. |
This Tube Condenser Microphone is professional for Interview, Live Chat, Recording, Live Streaming,Broadcasting, Conference, Speech, Gaming,Singing, Entertainment,Etc.
